MX-6 L4-1991cc 2.0L DOHC (1993)
NOTE: Mark the timing belt rotation on the belt for proper reinstallation.
Tensioner, Tensioner Spring installation Note
1. Measure the tensioner spring free length. If not within the specification, replace the tensioner spring.
Free length: 36.6 mm {1.44 inch}
2. Install the tensioner.
3. Rotate the tensioner. If tensioner rotates with no resistance or does not rotate, replace the tensioner.
