xB L4-1.5L (1NZ-FE) (2004)
/Page-870006.png)
b. Inspect the pull-in coil for open circuit.
1. Using an ohmmeter, check that there is continuity between terminals 50 and C.
If there is no continuity, replace the starter assy.
c. Check if the holding coil has an open circuit.
1. Using an ohmmeter, check that there is continuity between terminal 50 and the switch body.
If there is no continuity, replace the starter assy.
11. INSTALL STARTER CENTER BEARING CLUTCH SUB-ASSY
a. Install the drive lever set pin to the starter center bearing clutch.
b. Install the starter center bearing clutch w/ drive lever set pin to the starter drive housing.
12. INSTALL PLANET GEAR
a. Apply grease to the planet gears and pin parts of the planetary shaft.
b. Install the 3 planet gears.
