Page 3
background image

c. Using SST to hold the flange, torque the nut.

SST 09330-00021
Torque: 108 Nm (1,100 kgf-cm, 80 ft. lbs.)

10. ADJUST DRIVE PINION PRELOAD
11. STAKE DRIVE PINION NUT
12. INSTALL FRONT PROPELLER SHAFT

13. FILL DIFFERENTIAL WITH HYPOID GEAR OIL

Torque: 39 Nm (400 kgf-cm, 29 ft. lbs.)
Oil type: Hypoid gear oil API GL-5
Recommended oil viscosity: SAE 75W-90
Capacity: 1.15 liters (1.22 US qts, 1.01 Imp. qts)

14. INSTALL ENGINE UNDER COVER
