Crankshaft Balancer Installation
1. |
Align the bore (2) exactly
over the crankshaft pulley locating stud (1). |
2. |
Install the crankshaft
balancer (1). |
3. |
Install the 4 crankshaft
balancer bolts (2) and the spring washers and tighten to 20
N·m (15 lb ft) . |
|
