Timing Belt: Testing and Inspection
- Make
- Acura (Honda)
- Model
- RL
- Engine
- V6-3.7L
- Year
- 2009
- Section
- Timing Belt › Testing and Inspection
MaintenanceTesting and Inspection
Timing Belt: Testing and Inspection
Timing Belt Inspection
1. Remove the right upper fender trim.
2. Remove the drive belt. See: Drive Belt/Service and Repair
3. Remove the front upper cover.
4. Inspect the timing belt for cracks and oil or coolant contamination. Replace the belt if it is cracked, or is contaminated with oil or coolant. Wipe
off any oil or solvent that gets on the belt pulleys.
