TSX L4-2.4L (2005)
Flywheel: Service and Repair
Clutch Replacement
Special Tools Required
-
Clutch alignment disc 07JAF-PM7011A
-
Ring gear holder 07LAB-PV00100 or 07924-PD20003
-
Clutch alignment shaft 07ZAF-PR8A100
-
Remover handle 07936-3710100
Pressure Plate and Clutch Disc Removal
1. Check the height of the diaphragm spring fingers using the special tools and a feeler gauge. If the height is more than the service limit, replace the
pressure plate.
2. Install the special tools.
3. To prevent warping, unscrew the pressure plate mounting bolts (A) in a crisscross pattern in several steps, then remove the pressure plate (B).
4. Inspect the fingers of the diaphragm spring (A) for wear at the release bearing contact area.
