Fault-finding table

FAULT-FINDING TABLE

(1) Only for cars without ALFA ROMEO CODE, but with theft alarm: beforehand check that the theft alarm is working properly (see "Theft Alarm" section) as it may have cut off the supply to the starter motor.

(2) The instrument cluster C10 cannot be overhauled. Therefore, in the event of a fault it is not possible to replaced individual warning lights and a complete new instrument cluster must be installed.

(* TD version only, from chassis no.....; T.SPARK and JTD

CHECKING COMPONENTS

Ignition switch B1

Check the internal connections following the table below:

F2 Reed identification codes	POSITION OF KEY
	PARK	key can be removed	STOP key can be removed	DRIVE key not removable

Starter motor A11

If necessary, refer to the starter motor specifications and instructions given in the section "ELECTRIC SYSTEM-ENGINE STARTING"

Alternator A3

If necessary, refer to the starter motor specifications and instructions given in the section "ELECTRIC SYSTEM-CURRENT GENERATION"

Battery A1

If necessary, refer to the starter motor specifications and instructions given in the section "ELECTRIC SYSTEM-CURRENT GENERATION"
