General data and specificationsVehicle dimensions
VEHICLE DIMENSIONS
3 door versions
| 1.6 T.SPARK 105CV | 1.6 T.SPARK 120CV | 2.0 T.SPARK Selespeed | |
|---|---|---|---|
| A (mm) | 921 | 921 | 921 |
| B (mm) | 2546 | 2546 | 2546 |
| C (mm) | 703 | 703 | 703 |
| D (mm) | 4170 | 4170 | 4170 |
| E (mm) | 1442 (a) | 1442 (b) | 1436 (b) - 1421 (c) |
| F (mm) | 1516 (a) (.) | 1516 (b) (.) | 1509 (b) (.) - 1510 (c) (.) |
| G (mm) | 1892 | 1892 | 1892 |
| H (mm) | 1729 | 1729 | 1729 |
| I (mm) | 1504 (a) (.) | 1504 (b) (.) | 1496 (b) (.) - 1497 (c) (.) |
