Illustrated index (page 2 of 2)

Make

Alfa Romeo

Model

155 Factory Service Manual

Year

1992–1998

Section

Illustrated index

DoorsIllustrated index · page 2 of 2

1. GUIDE PAD Page 55-25
2. WINDOW SEALS Page 55-33
3. WINDOW RAISING DEVICE Page 55-31
4. WINDOWS Page 55-24
5. FIXED WINDOWS Page 55-32
6. GUIDE WINDOWS Page 55-25
7. REAR DOORS Page 55-20
8. OUTSIDE DOOR HANDLE Page 55-32
9. LOCK DEVICE Page 55-30
10. TRIANGULAR MOULDING FOR FIXED WINDOWS Page 55-34
11. DOOR CATCH Page 55-21
12. LOWER DOOR FINISHING STRIP Page 55-33
13. DOOR CHECK-STRAP Page 55-23
14. PANEL (vehicles without power windows) Page 55-21
15. PANEL (vehicles with power windows) Page 55-22
16. FRAME(vehicles without power windows) Page 55-26
17. FRAME(model with power steering) Page 55-28

61 Body & interior
