Removal and refitting

REMOVAL AND REFITTING

• Disconnect the negative (-) cable from the battery.
• Remove the door panel (see: PANEL).
• Remove the door frame (see: FRAME).

1. Loosen the three screws securing the lock device to the door and remove them along with their washers.
2. Remove the lock device.

To refit, reverse the procedure followed for removal and observe the following:

• Before connecting the electrical connectors, check that the electrical cables are correctly inserted.
• For the refitting of components dealt with in other pages of this or other groups, refer to the relevant procedures and advice (see: PANEL, FRAME).
• After refitting adjust the catch of the lock device on the door pillar (see: DOOR CATCH).
• Tighten the retaining screws to the correct torque.

1. Lock device
2. Retaining screws

7.1 – 9 Nm
(0.72 ÷ 0.92 kgm)
