Alfa Romeo GTV and Spider (916) Factory Service Manual (1995-2000)11 · Variants – 2.0 V6 Turbo (GTV and Spider)
11 · General

Model identification

Make
Alfa Romeo
Model
GTV / Spider GTV and Spider (916) Factory Service Manual
Year
1995–2000
Section
Vehicle › Model identification
Variants – 2.0 V6 Turbo (GTV and Spider)Model identification

MODEL IDENTIFICATION

Brand nameGTV V6 TB
VersionCoupé
Version (on identification plate)916C2A
Chassis (in engine compartment, on upper right-hand shock absorber bracket)-
Progressive chassis number6000001
Engine (code)AR 16202
Engine symbol1996 TB
Gearbox (code)C.503.5.29.21

IDENTIFICATION PLATE LOCATION

Top view of the car showing identification plate locations 1, 2 and 3
V6 TB engine showing the engine marking 4
  1. Identification data plate
  2. Chassis marking
  3. Paintwork identification plate
  4. Engine marking
