Pressure-temperature graphs › High Side (lbf/in²) - Ambient (°C)
Air conditioningHigh Side (lbf/in²) - Ambient (°C)

To obtain Bar multiply the lbf/in² by 0.068
To obtain kgf/cm² multiply lbf/in² by 0.07

High Side (lbf/in²) - Ambient (°C)

Pressure-Temperature Graph for High Side (lbf/in²) vs Ambient Temperature (°C), ranging from 15°C to 49°C and 100 lbf/in² to 400 lbf/in².

Low Side (lbf/in²) - Ambient (°C)

Pressure-Temperature Graph for Low Side (lbf/in²) vs Ambient Temperature (°C), ranging from -8°C to 21°C and 10 lbf/in² to 80 lbf/in².
