Timing Belt: Specifications (page 4 of 9)
- Make
- Audi
- Model
- TT
- Engine
- L4-1.8L Turbo (BEA)
- Year
- 2004
- Section
- Timing Belt
MaintenanceSpecifications · page 4 of 9
/Page-1059002.png)
18 - 20 Nm
19 - Toothed belt guard, center
20 - Toothed belt guard, bottom
21 - 10 Nm
Removing toothed belt
Special tools, testers and workshop equipment required:
^
10 - 222A
^
10 - 222A/1
^
Engine, disassembling and assembling
^
Engine in vehicle
^
Disconnect air duct at bottom of right - hand longitudinal member (air duct leads to charge air cooler).
