5 Series E39 M5 (S62) SAL
Slacken six accessible bolts two turns.
Crank engine at central bolt in direction of rotation until 1st
cylinder is at TDC firing position. Secure vibration damper in
position with special tool 11 2 300 .
Slacken remaining six bolts two turns.
Note:
The camshafts have an opening. The 1st bearing caps have a
locating bore.
Align camshaft opening to locating bore in bearing cap and secure
in position with special tool 11 7 120 .
RA Removing and installing/replacing toothed shafts of VANOS gear on right (S62)
