Catera V6-3.0L VIN R (1997)

Page 1
background image

Rear Door Panel: Service and Repair
Bracket

REMOVAL PROCEDURE

Trim Panel Bracket Replacement (Rear Door): Removal Procedure

1. Remove the trim panel.
2. Remove the trim panel retaining block.

INSTALLATION PROCEDURE

Trim Panel Bracket Replacement (Rear Door): Installation Procedure

1. Install the retaining block.
2. Install the trim panel.
