Catera V6-3.0L VIN R (1997)
Rear Door Panel: Service and Repair
Main Panel
REMOVAL PROCEDURE
Trim Panel Replacement (Side Rear Door): Removal Procedure
1. Remove the assist handle and cover.
2. Remove the courtesy lamp.
3. Remove the trim panel screws.
Trim Panel Replacement (Side Rear Door): Removal Procedure
4. Lift upward on the trim panel until released from the clips.
INSTALLATION PROCEDURE
Trim Panel Replacement (Side Rear Door): Installation Procedure
1. Hook the upper edge of the trim panel on the clips.
