Catera V6-3.0L VIN R (1997)
Seat Cushion: Service and Repair
Seat Cushion Release Handle Replacement
REMOVAL PROCEDURE
Seat Cushion Release Handle Replacement: Removal Procedure
1. Remove the rear seat cushion. Rear Seat Cushion.
2. Remove the rear seat cushion release hinge handle.
^
Put down a protective cover to prevent damage to rear seat cushion cover.
^
Unsnap cover and pull out center pin to release hinge and cover from the frame.
INSTALLATION PROCEDURE
Seat Cushion Release Handle Replacement: Installation Procedure
1. Install the rear seat cushion release hinge handle.
2. Install the rear seat cushion release hinge handle.
^
Put down a protective cover to prevent damage to rear seat cushion cover.
^
Install cover and hinge to the frame. Insert the center pin and snap the cover closed.
3. Install the rear seat cushion.
