Catera V6-3.0L VIN R (1997)
Seat Cushion: Service and Repair
Seat Cushion Replacement: Rear
REMOVAL PROCEDURE
Seat Cushion Replacement (Rear): Removal Procedure
1. Remove the rear seat cushion
Pull the release handles which are located at the base of rear seat cushion.
Seat Cushion Replacement (Rear): Removal Procedure
2. Remove the rear seat cushion heating element electrical connectors (1).
3. Remove the rear seat belt from lower seat cushion.
4. Remove the rear seat cushion from vehicle.
INSTALLATION PROCEDURE
Seat Cushion Replacement (Rear): Installation Procedure
