Catera V6-3.0L VIN R (1997)
Description
10. Clamp the pretensioner, near the attachment bolt hole, in the vice.
Description
11. Extend the SIR deployment harness and adapter to full length from the seat belt pretensioner.
12. Place a 12V minimum/2A minimum power source (i.e., vehicle battery) near the shorted end of the harness.
Description
13. Connect the seat belt pretensioner (1) to the adapter (2) on the SIR deployment harness (3).
