Catera V6-3.0L VIN R (1997)
Description
17. Twist together, bend, and tape the remaining connector wire lead to the remaining deployment wire.
18. Connect the deployment harness to the 8-way driver seat connector 0315, located under the LH front seat track cover.
19. Route the deployment harness out of the LH side of the vehicle.
20. Disconnect the 8-way driver seat connector 0316, located under the RH front seat track cover.
