Catera V6-3.0L VIN R (1997)
5. Insert the rear wheel J 42094-9 on the shaft of the J 42094-3. Ensure that the rear wheel J 42094-9 is on the inner ring of the wheel bearing.
6. Attach the J 42094-1 to J 42094-7.
7. Remove the supplied anchoring bolts from the J 42094-4.
8. Thread the rear wheel hub into the J 42094-3.
Important:
^
Center the J 42094-3 inside of the wheel bearing to prevent binding of the rear wheel hub while drawing it into the bearing.
^
Adjust the J 42094-7 if necessary.
9. Draw the rear wheel hub into the wheel bearing by holding the J 42094-3 and turning the J 42094-4 clockwise.
10. Remove the tool assembly from the vehicle.
