Catera V6-3.0L VIN R (1997)
18. Install the retaining washer.
19. Install the peen retaining washer to the rear wheel hub.
^
Use the J 36660 to tighten the brake backing plate bolts to 50 Nm (37 ft. lbs.) + 40°.
20. Install the rear brake caliper.
21. Install the brake pipe to the lower control arm.
22. Secure the brake pipe to the lower control arm with a clip.
23. Install the drive shaft to the rear wheel hub flange.
24. Use the J 42066 to counter hold the rear wheel hub.
25. Install the drive shaft bolts.
^
Use J 36660 to tighten the drive shaft bolts to 50 Nm (37 ft. lbs.) + 70°.
26. Install the tire and wheel assembly.
27. Lower the vehicle.
