Grille: Service and Repair
Grille Replacement
Removal Procedure
1. Remove the front bumper fascia. Refer to Front Bumper Fascia Replacement .
2. Remove the push-in retainers that hold the grille to the fascia.
3. Remove the grille from the fascia.
Installation Procedure
1. Position the grille to the fascia.
2. Install the push-in retainers that hold the grille to the fascia.
3. Install the fascia to the vehicle. Refer to Front Bumper Fascia Replacement .
