CTS V8-6.0L (2007)
Fluid - Differential: Procedures
Lubricant Level Inspection - Rear Drive Axle
Inspection Procedure
1. Raise and support the vehicle. Refer to Vehicle Lifting.
2. Clean any dirt from around the differential fill plug.
3. Remove the fill plug from the differential and drain the fluid.
4. Check the differential fluid level. it should be even with the bottom of the fill plug hole to no lower than 6 mm (0.25 in) below the opening.
5. Add new fluid if necessary.
6. Fill the differential with 75W90 synthetic axle lubricant, GM P/N 12378261 (Canadian P/N 10953455) or equivalent. Refer to Lubrication
Specifications.
Notice: Refer to Fastener Notice.
7. Install the differential fill plug to the differential.
Tighten the differential fill plug to 39 N.m (29 lb ft).
8. Lower the vehicle.
