CTS V8-6.0L (2007)

Page 1
background image

Wiper Switch: Locations

Wiper/Washer Component Views

Windshield Wiper Subsystem Components

1 - Windshield Wiper/Washer Module
2 - Windshield Wiper/Washer Module Connector
3 - Windshield Wiper/Washer Switch (LHD shown, RHD similar)
4 - Steering Wheel (LHD shown, RHD similar)
