CTS AWD V6-3.6L (2009)
Dimmer Switch: Locations
Instrument Panel/Center Console Component Views
Instrument Panel Overview
1 - Speaker - Left Front
2 - Turn Signal/Multifunction Switch
3 - Steering Wheel Control Switch - Left
4 - Instrument Panel Cluster (IPC)
5 - Steering Wheel Control Switch - Right
6 - Windshield Wiper/Washer Switch
7 - Sunload Sensor
8 - Speaker - Center I/P
9 - Analog Clock
10 - Inflatable Restraint I/P Module
11 - Speaker - Right Front
12 - I/P Compartment Lamp
13 - Hazard Switch
14 - Radio/Navigation Unit
15 - Heated Seat Switch - Front Passenger Seat
16 - Accessory Power Outlet - Center Console
