Ignition Coil: Locations
- Make
- Cadillac
- Model
- CTS RWD
- Engine
- V6-3.6L
- Year
- 2008
- Section
- Ignition System › Ignition Coil › Locations
Powertrain ManagementLocations · page 1 of 14
Ignition Coil: Locations
Powertrain Component Views
Engine-Right Front (LLT/LP1/LY7)
1 - Throttle Body (LLT/LP1/LY7)
2 - Intake Manifold Tuning (IMT) Solenoid Valve (LLT/LP1/LY7)
3 - Ignition Coil 5 (LLT/LP1/LY7)
4 - Ignition Coil 3 (LLT/LP1/LY7)
5 - Ignition Coil 1 (LLT/LP1/LY7)
6 - Engine Coolant Temperature (ECT) Sensor (LLT/LP1/LY7)
7 - Knock Sensor (KS) 2
8 - A/C Compressor Clutch
9 - Knock Sensor (KS) 1
10 - Crankshaft Position (CKP) Sensor
Engine-Right Rear (LLT/LP1/LY7)
