CTS RWD V8-6.2L SC (2009)
Vehicle Lifting: Service and Repair
Lifting and Jacking the Vehicle
Jacking Points for Lifting Equipment
Lifting and Jacking Points
Danger: To avoid any vehicle damage, serious personal injury or death when major components are removed from the vehicle and the vehicle
is supported by a hoist, support the vehicle with jack stands at the opposite end from which the components are being removed and strap the
vehicle to the hoist.
Warning
To help avoid personal injury, always use jack stands when you are working on or under any vehicle that is supported only by a jack.
Caution: When you are jacking or lifting a vehicle at the frame side rails or other prescribed lift points, be certain that the lift pads do not contact the
catalytic converter, the brake pipes or the fuel lines. If such contact occurs, vehicle damage or unsatisfactory vehicle performance may result.
Before beginning any lifting procedure, be sure the vehicle is on a clean, hard, level surface. Be sure all the lifting equipment meets weight standards and
is in good working order. Be sure all the vehicle loads are equally distributed and secure. If the vehicle is only being supported at the frame side rails,
