SRX AWD V6-3.6L (2008)
Exhaust Manifold: Service and Repair
Exhaust Manifold Replacement - Left Side
Exhaust Manifold Replacement - Left Side (LY7 - Gas, 6 Cylinder, 3.6L, SFI, V6)
Removal Procedure
Caution: Refer to Exhaust Service Caution (See: Service Precautions) .
Caution: Refer to Protective Goggles and Glove Caution (See: Service Precautions/Technician Safety Information/Protective Goggles and Glove
Warning) .
1. Remove the exhaust manifold heat shield. Refer to Exhaust Manifold Heat Shield Replacement - Left Side (LY7 - Gas, 6 Cylinder, 3.6L, SFI, V6)
(See: Heat Shield/Service and Repair/Exhaust Manifold Heat Shield Replacement - Left Side)Exhaust Manifold Heat Shield Replacement - Left
Side (V8 w/LHD) (See: Heat Shield/Service and Repair/Exhaust Manifold Heat Shield Replacement - Left Side (V8 w/LHD)) .
2. Remove the oil level indicator. Refer to Oil Level Indicator and Tube Replacement (See: Engine/Engine Lubrication/Engine Oil Dip Stick - Dip
Stick Tube/Service and Repair) .
3. Remove the catalytic converter nuts.
4. Remove the exhaust manifold bolts.
Important: Do not reuse the gasket.
5. Remove the exhaust manifold and discard the exhaust manifold gasket.
6. Clean and inspect the exhaust manifold. Refer to Exhaust Manifold Cleaning and Inspection - Left Side (See: Engine/Service and Repair/Overhaul
) .
Installation Procedure
