SRX AWD V6-3.6L (2008)
Important: Inspect the catalytic converter seal/heat shield sealing surface. Replace the seal/heat shield if the sealing surface is worn or
damaged.
1. Install the catalytic converter seal/heat shield to the catalytic converter.
2. Install a NEW exhaust manifold gasket to the exhaust manifold.
3. Install the exhaust manifold with the gasket to the catalytic converter and the cylinder head.
Notice: Refer to Fastener Notice (See: Service Precautions/Vehicle Damage Warnings/Fastener Notice) .
4. Install the exhaust manifold bolts.
Tighten the exhaust manifold bolts to 20 N.m (15 lb ft).
5. Install the catalytic converter nuts.
Tighten the catalytic converter nuts to 50 N.m (37 lb ft).
6. Install the oil level indicator. Refer to Oil Level Indicator and Tube Replacement (See: Engine/Engine Lubrication/Engine Oil Dip Stick - Dip
Stick Tube/Service and Repair) .
7. Install the exhaust manifold heat shield. Refer to Exhaust Manifold Heat Shield Replacement - Left Side (LY7 - Gas, 6 Cylinder, 3.6L, SFI, V6) (
See: Heat Shield/Service and Repair/Exhaust Manifold Heat Shield Replacement - Left Side)Exhaust Manifold Heat Shield Replacement - Left
Side (V8 w/LHD) (See: Heat Shield/Service and Repair/Exhaust Manifold Heat Shield Replacement - Left Side (V8 w/LHD)) .
