STS RWD V8-4.6L (2007)
Important: The front hoist pads must not contact the rocker panels, the front fenders, the floor pan, or the stone guard moldings. Do no lift the
vehicle by the metal flange located behind the triangle or the rocker molding.
Position the frame contact front hoist pads as follows:
*
Under the front frame rail.
*
The long sides of the pads, if applicable parallel to the frame rails.
Rear Hoist Pads
Important: The rear hoist pads must not contact the rocker panels, the rear fenders, the floor pan, or the stone guard moldings.
Position the frame contact rear hoist pads as follows:
*
Under the rear frame rail at the rear axle cradle mount flange.
*
The long sides of the pads, if applicable perpendicular to the frame rails.
Floor Jacks
When lifting a vehicle with a floor jack, block the wheels at the opposite end from which the vehicle is being lifted. Use jack stands to provide additional
support.
Under the Frame Rail Reinforcements
Important: The floor jack pad must not contact the rocker panels, the floor pan, or the stone guard moldings.
Position the floor jack pad under the front frame rail reinforcement or under the rear frame rail at the rear axle cradle mount flanges.
Under the Engine Front Crossmember Frame
