Flex Plate: Service and Repair
Engine Flywheel Replacement
Tools Required
*
J 45059 Angle Meter
*
EN 46326 Flywheel Holding Tool
Removal Procedure
1. Remove the powertrain.
2. Remove the driveline support assembly.
3. Remove the intake manifold.
4. Install the EN 46326.
5. Remove the engine flywheel bolts.
6. Remove the flywheel and the reinforcement.
7. Clean and inspect the engine flywheel.
Installation Procedure
1. Apply sealant to the flywheel mounting bolts.
