23. Remove the I/P compartment striker from the I/P carrier.
24. Remove the I/P carrier from the mounting and slowly route all of the wiring from the I/P carrier.
25. Remove the I/P carrier from the vehicle.
Installation Procedure
1. Position the I/P carrier to the lower and the upper I/P beams.
2. Route the I/P wiring harness.
Notice: Refer to Fastener Notice in Service Precautions.
3. Install the retaining bolts and nuts to the I/P carrier.
Tighten the bolts to 10 N.m (89 lb in).
