Chevrolet Aveo L4-1.6L (2008)|Filters > < Engine - Drive Belt Misalignment Diagnostics|Page 1368

Aveo L4-1.6L (2008)

Page 2
background image

1. With the J 23600-B on the pump drive belt, loosen the alternator adjusting bolt and move the alternator until the gage indicates the proper tension.

Notice: Refer to Fastener Notice (See: Service Precautions/Vehicle Damage Warnings/Fastener Notice).

2. Tighten the alternator adjusting bolt.

Tighten the alternator adjusting bolt to 20 N.m (15 lb ft).
