Ignition Coil: Locations
- Make
- Chevrolet
- Model
- HHR
- Engine
- L4-2.0L Turbo
- Year
- 2010
- Section
- Ignition System › Ignition Coil › Locations
Powertrain ManagementLocations · page 1 of 8
Ignition Coil: Locations
Powertrain Component Views
Engine - Top (LNF)
1 - Ignition Coil 2
2 - Ignition Coil 3
3 - Ignition Coil 4
4 - Fuel Injector 4
5 - Fuel Injector 3
6 - Fuel Injector 2
7 - Fuel Injector 1
8 - Camshaft Position (CMP) Actuator Solenoid Exhaust
9 - Camshaft Position (CMP) Actuator Solenoid Intake
10 - Ignition Coil 1
