Flywheel: Specifications
- Make
- Dodge
- Model
- Dakota 4WD
- Engine
- V8-4.7L VIN N
- Year
- 2000
- Section
- Flywheel › Specifications
Flywheel: Specifications
Torque Specifications
Torque Specifications
Engine
Component
Torque
2.5 L
Flywheel Bolts
Tighten to 68 Nm. Turn an additional 60 degrees.
New bolts MUST be used when installing the flywheel or
converter plate.
3.9 L
"
75 Nm (55 ft. lbs.)
4.7 L
"
60 Nm (45 ft. lbs.)
Follow the tightening sequence in the image provided.
5.9 L
"
75 Nm (55 ft. lbs.)
Pinch or Ctrl + scroll to zoom. Double-tap to reset.
The same page in: Dakota 2WD L4-2.5L VIN P (2001), Dakota 2WD V8-4.7L VIN N (2001), Dakota 2WD V8-5.9L VIN Z LDC (2000), Dakota Quad Cab 2WD V8-4.7L VIN N (2001), Dakota Quad Cab 4WD V6-3.9L VIN X (2001), Dakota Quad Cab 4WD V8-5.9L VIN Z LDC (2001).
