L030 EGR solenoid

Make

Fiat

Model

Doblò Factory Service Manual

Year

2000–2010

Section

Electromagnets and solenoid valves › L030 EGR solenoid

Connectors and pin-outsL030 EGR solenoid

L030 EGR SOLENOID

1.9 JTD 8V · from 12/03 · DPF, MY 2005

Wiring	Colour
See 50 ENGINE	GRIGIO

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1	1	LN	X	See M015A PLUG PREHEATING CONTROL UNIT (INJECTION BRAID / ENGINE SERVICES)	3
				See K84 SPEEDOMETER SENSOR	3
				See K040 LAMBDA SENSOR	K
				See L037 WASTE GATE SOLENOID VALVE	2
				See B001F JUNCTION UNIT (INJECTION BRAID / ENGINE SERVICES)	7
5	1	HL		See M010B ENGINE MANAGEMENT ECU (ENGINE)	60

1.9 JTD 8V · from 12/03 · MY 2005

Wiring	Colour
See 50 ENGINE	GRIGIO

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1	1	LN	X	See M015A PLUG PREHEATING CONTROL UNIT (INJECTION BRAID / ENGINE SERVICES)	3
				See K84 SPEEDOMETER SENSOR	3
				See K040 LAMBDA SENSOR	K
				See L037 WASTE GATE SOLENOID VALVE	2
				See B001F JUNCTION UNIT (INJECTION BRAID / ENGINE SERVICES)	7
				See L062 THROTTLE CASING SOLENOID	2
5	1	HL		See M010B ENGINE MANAGEMENT ECU (ENGINE)	60

1.3 JTD 16V · from 12/03 · MY 2005

Wiring	Colour
See 50 ENGINE	GRIGIO

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1	0,75	LR	X	See M010B ENGINE MANAGEMENT ECU (ENGINE)	5
				See L036 TURBINE VARIABLE GEOMETRY CONTROL SOLENOID VALVE	2
				See D029 ENGINE CABLES/ENGINE SERVICES CABLE COUPLING	3
5	0,75	HR		See M010B ENGINE MANAGEMENT ECU (ENGINE)	15

L30 – Engine

1.9 DIESEL

Wiring	Colour
See 50 ENGINE	nero

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1	0,5	CR	x	See L62 BUTTERFLY CASING SOLENOID VALVE ( ENGINE )	1
			x	See K84 SPEEDOMETER SENSOR ( ENGINE )	3
			x	See M15A HEATER PLUGS CONTROLUNIT ( ENGINE )	3
			x	See B1F ENGINE COMPARTMENT JUNCTION UNIT ( ENGINE )	7
2	0,5	G		See M010 ENGINE MANAGEMENT ECU	39
4	0,5	VN		See M010 ENGINE MANAGEMENT ECU	63
5	0,5	BL		See M010 ENGINE MANAGEMENT ECU	59
6	0,5	S		See M010 ENGINE MANAGEMENT ECU	35

1.9 JTD 8V

Wiring	Colour
See 50 ENGINE	nero

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
3	0,75	CR	x	See L62 BUTTERFLY CASING SOLENOID VALVE ( ENGINE )	2
			x	See L35 WASTE-GATE SOLENOID VALVE ( ENGINE )	2
			x	See K041 AIR FLOW METER	2
			x	See B1F ENGINE COMPARTMENT JUNCTION UNIT ( ENGINE )	7
			x	See K84 SPEEDOMETER SENSOR ( ENGINE )	3
			x	See M15A HEATER PLUGS CONTROLUNIT ( ENGINE )	3
			x	See K31 WATER IN DIESEL FILTER SENSOR ( ENGINE )	3
5	0,75	BL		See M10B ENGINE MANAGEMENT ECU ( ENGINE )	16

1.2 8v, 1.6 16v, 1.3 JTD 16V, 1.9 JTD 8V, 1.9 DIESEL

Wiring	Colour
See 50 ENGINE	nero

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1	0,75	BZ	X	See B1F ENGINE COMPARTMENT JUNCTION UNIT ( ENGINE )	7
				See K84 SPEEDOMETER SENSOR ( ENGINE )	3
				See M15A HEATER PLUGS CONTROLUNIT ( ENGINE )	3
				See B1F ENGINE COMPARTMENT JUNCTION UNIT ( ENGINE )	6
				See M10A ENGINE MANAGEMENT ECU ( ENGINE )	5
5	0,75	BZ		See M10A ENGINE MANAGEMENT ECU ( ENGINE )	15
