00 Introduction and technical dataSpecial tools
Special tools
00.A
| Tool number |
DESCRIPTION OF TOOL | ENGINE |
|---|---|---|
| 1581 SPI | ||
| 1890310000 | Reamer (8 mm dia) for valve guide bores | ● |
| 1890365000 | Reamer for auxiliary shaft bushes | ● |
| 1895683000 | Device for checking engine cylinder compression (scale 4,05 - 18,2 bar) | ● |
| 1895683002 | Cards for tool 1895683000 | ● |
| 1895762000 | Dynamometer to check V and poly-V belt tension | ● |
| 1895868000 | Valve leakage test equipment | ● |
| 1895890000 | Fuel pump delivery pressure gauge with unions | ● |
| 1896219000 | Gauge to check valve stem height after valve seat grinding | ● |
