RADIO WIRING DIAGRAM

Wiring Diagram

Components

Component code	Description	Reference to the assembly
C015	Driver''s dashboard earth
C020	Passenger dashboard earth
C022	Centre dashboard earth
D020	Dashboard/rear coupling
D030	Left front door coupling
D031	Right front door coupling
E050	Instrument panel	5560B
M001	Body computer	5505A
M093	Steering wheel node control unit (NVO)	5550A
M140	Warning lights and milometer control unit (NSO)
M172	Multifunction screen node
P020	Radio
P025	Aerial feed/amplifier
P035	Speaker in left front door	5570T
P036	Speaker in right front door	5570T
P045	Left front tweeter speaker	5570T
P046	Right front tweeter speaker	5570T
P047	Left rear tweeter speaker	5570T
P048	Right rear tweeter speaker	5570T
P075	CD player/changer
P120	Leaf rear speaker in side panel
P121	Right rear speaker in side panel
