RADIO - WIRING DIAGRAM

2.0 16V JTD, 2.2 16V JTD · MY 2005

Components

Component code	Description	Reference to the assembly
B001	ENGINE COMPARTMENT JUNCTION UNIT	Op. 5505A MULTI-FUNCTION COMPONENTS
C015	DRIVER''S DASHBOARD EARTH
C020	PASSENGER SIDE DASHBOARD EARTH
C022	Centre dashboard earth
D006	FRONT/REAR COUPLING
D020	DASHBOARD/REAR COUPLING
D030	DRIVER''S FRONT DOOR COUPLING
D031	PASSENGER FRONT DOOR COUPLING
E050	INSTRUMENT PANEL	Op. 5560B ANALOGUE CONTROL PANEL
H001	Ignition switch	Op. 5520A IGNITION SWITCH
M001	BODY COMPUTER	Op. 5505A MULTI-FUNCTION COMPONENTS
M093	STEERING WHEEL NODE CONTROL UNIT (NVO)	Op. 5550A STALK UNIT
M140	WARNING LIGHTS AND MILOMETER CONTROL UNIT (NSO)
M172	MULTIFUNCTION SCREEN NODE
P020	RADIO
P025	AERIAL FEED/AMPLIFIER
P035	SPEAKER IN LEFT FRONT DOOR	Op. 5570T CAR RADIO AND CAR TELEPHONE
P036	SPEAKER IN RIGHT FRONT DOOR	Op. 5570T CAR RADIO AND CAR TELEPHONE
P045	LEFT FRONT TWEETER SPEAKER	Op. 5570T CAR RADIO AND CAR TELEPHONE
P046	RIGHT FRONT TWEETER SPEAKER	Op. 5570T CAR RADIO AND CAR TELEPHONE
P047	LEFT REAR TWEETER SPEAKER	Op. 5570T CAR RADIO AND CAR TELEPHONE
P048	RIGHT REAR TWEETER SPEAKER	Op. 5570T CAR RADIO AND CAR TELEPHONE
P075	CD CHANGER MODULE
P120	LEAF REAR SPEAKER IN SIDE PANEL
P121	RIGHT REAR SPEAKER IN SIDE PANEL
