E 150 V8-4.6L (2007)
Intake Manifold: Overhaul
Intake Manifold Assembly - 4.6L
Material
Disassembly
WARNING: Do not smoke or carry lighted tobacco or open flame of any type when working on or near any fuel-related components. Highly
flammable mixtures are always present and can be ignited. Failure to follow these instructions may result in personal injury.
1. Remove the 4 fuel rail stud bolts.
2. NOTE: When removing the fuel rail, leave the fuel injectors in the intake manifold. This will make removal of the fuel rail easier.
Separate the fuel rail from the fuel injectors and remove the fuel rail.
