Explorer 4WD V6-245 4.0L (1991)
FIGURE 4
9.
On the rear latch mechanism, cut off the safety hook flush with the edge using side cutters. (See Fig.4)
10.
Remove the two screws from the striker plate.
11.
Install metal bracket using screws as shown. (See Fig. 4) Torque to 12-15 in.lbs. (1.3-1.7 Nm).
12.
Reinstall Sunroof glass panel in vehicle.
Owner Letter
Serial Number:
12345678901234567 S08 June, 1990
Mr. John Sample 123 Main Street Anywhere, USA 12345
This notice is sent to you in accordance with the requirements of the National Traffic and Motor Vehicle Safety Act.
