14. Install the valve housing in the Bench Mounted Holding Fixture and loosen the setscrew.

15. Use Adjuster and Lock Nut Wrench to remove the race nut.

16. Remove the power steering gear input shaft and control from the valve housing.
17. Rotate the valve housing with the Bench Mounted Holding Fixture.

18. Use the Puller to remove the power steering gear input shaft seal dust seal.
