Flex Plate: Specifications
- Make
- GMC
- Model
- Canyon 4WD
- Engine
- V8-5.3L
- Year
- 2009
- Section
- Flex Plate › Specifications
Flex Plate: Specifications
FLYWHEEL/FLEXPLATE
Automatic Transmission Flex Plate Bolts
First Pass.......................................................................................................................................................................................................20 Nm (15 lb ft)
Second Pass...................................................................................................................................................................................................50 Nm (37 lb ft)
Final Pass....................................................................................................................................................................................................100 Nm (74 lb ft)
