Flywheel: Specifications
FLYWHEEL/FLEXPLATE
Engine Flywheel bolts
First pass in sequence to................................................................................................................................................................................20 Nm (15 lb ft)
Second pass in sequence to...........................................................................................................................................................................50 Nm (37 lb ft)
Final pass in sequence to.............................................................................................................................................................................100 Nm (74 lb ft)
