Timing Belt: Service and Repair

Timing Components (D15B7)

REMOVAL

CAUTION: Inspect the water pump when replacing the timing belt.

NOTE:

^

Turn the crankshaft so that No. 1 piston is at top- dead-center.

^

Before removing the timing belt, mark its direction of rotation if it's to be reused.
