Timing Belt: Diagrams (page 9 of 10)
- Make
- Honda
- Model
- Del Sol
- Engine
- L4-1.5L SOHC
- Year
- 1993
- Section
- Timing Belt
MaintenanceDiagrams · page 9 of 10
5. Rotate the crankshaft about 4 or 6 turns counterclockwise so that the belt positions on the pulleys.
6. Adjust the timing belt tension.
7. Check the crankshaft pulley and the camshaft pulley at TDC.
