Subframe: Service and Repair
- Make
- Honda
- Model
- Fit
- Engine
- L4-1.5L
- Year
- 2008
- Section
- Frame › Subframe › Service and Repair
Body and FrameService and Repair
Subframe: Service and Repair
Subframe Replacement
Front Subframe Torque
NOTE:
-
After loosening the subframe mounting bolts, be sure to replace them with new ones.
-
When installing, align both installation reference holes in the subframe with both reference holes in the body using a screwdriver or tapered punch
as a guide.
