H3 L5-3.7L (2007)
4. Adjust at the upper control arm.
5. Remove the pinned adjusting cam insert. Do not reinstall the cam insert.
6. Loosen the control arm cam adjustment bolts.
Notice: Refer to Fastener Notice.
7. Using the J 45938 adjust the caster and the camber angle by turning the cam bolts until the specifications have been met.
When the adjustments are complete, hold the cam bolt in order to ensure the cam bolt position does not change while tightening the nut.
Tighten the cam nuts to 155 N.m (114 lb ft).
8. Verify that the caster and the camber are still within specifications. Refer to Wheel Alignment Specifications.
When the caster and camber are within specifications, adjust the toe. Refer to Front Toe Adjustment.
Front Toe Adjustment
Front Toe Adjustment
