Timing Belt: Specifications (page 3 of 15)

Make

Hyundai

Model

Accent

Engine

L4-1.6L

Year

2003

Section

Timing Belt

MaintenanceSpecifications · page 3 of 15

Timing Belt: Adjustments

ADJUSTING TIMING BELT TENSION

1. Rotate the steering wheel counter-clockwise thoroughly.

NOTE: Do watch not to over load.

2. Lift the vehicle by using of jack.

3. Remove the engine support bracket. (14mm bolt and 2nuts, 17mm bolt)

4. Remove the drive belts and the water pump pulley. (10 mm 4 bolts)
